Understand the knowledge of laser cutting machine

The working principle of laser cutting machine
Laser cutting is used to illuminate the workpiece with high power density laser beam,to make the workpiece rapidly melt, vaporize, abate or reach the point of ignition, at the same time, the molten material is blown out by the high-speed airflow which is coaxial with the beam to the workpiece, through moving light spot position by the CNC mechanical system to cut workpiece.

Precautions for the operation of laser cutting machine
1.Beware of flammable materials when using machine.Some materials could not be cut by laser cutting machine, including foaming core material, all the PVC materials, high reflective material and so on.
2.In the machine working process, the operator is forbidden to leave to avoid unnecessary losses.
3.Don't stare at the laser cutting processing. It is forbidden to observe the laser beams through binoculars, microscope or magnifying glasses.
4.Do not put explosive or flammable materials in the laser processing area.

Factors affecting laser cutting accuracy
There are many factors can affect the laser cutting accuracy, some factors are caused by the equipment itself, such as mechanical system precision, table vibration level, laser beam quality, auxiliary gas, nozzle etc, some factors are inherent material factors, such as the physical and chemical properties of materials , the reflectivity of the material, etc.Other factors like parameters can be adjusted based on the specific processing object and the user's quality requirements, such as output power, focal position, cutting speed, auxiliary gas etc.

The method of laser cutting machine to find the focus
Laser power density has a great influence on the cutting speed, so the selection of the focal position is particularly important. The spot size of the laser beam is proportional to the length of the lens. There are three simple ways to find the cutting focus position in the industrial files:
1.Pulse method: Let laser beam print on a plastic sheet,moving the laser head from top to bottom,checking all holes and the smallest diameter is the focus.
2.Slant plate method: Using a slant plate under the vertical axis, moving it horizontally and looking for the laser beam at the minimum focus.
3.Blue Spark: Remove the nozzle, blow the air, pulse on stainless steel plate, move the laser head from top to bottom, until find the blue spark as the focus.

At present, many manufacturers’ machines have automatic focus.Automatic focus can significantly improve the laser cutting machine’ efficiency, piercing time on thick plate is significantly reduced; The machine can adjust automatically to find the focus position based on different materials and thickness.

The above is the relevant introduction of the laser machine that ACCTEK has arranged for you. If you want to know the details and price of the laser cnc machines, you can consult online, and our staff will reply to you in time. I hope it helps you.
